Kitchen toe kick dimensions: plinth height, recess and fitting checks

Short answer: a practical UK kitchen toe kick usually sits somewhere around 100 to 165 mm high with a recess around 50 to 75 mm deep. The exact size comes from the cabinet legs, plinth system, floor level and target worktop height. Do not cut plinths until the base units are level and the finished floor detail is known.

The toe kick, also called the plinth or kickboard space, is easy to ignore until the kitchen feels awkward. Too shallow and your toes hit the cabinet. Too tall and the plinth looks odd or loses strength. Too low and uneven floors become obvious.

Kitchen toe kick dimensions diagram showing plinth height and toe recess under base cabinets — A toe kick is a comfort and fitting detail, not a random gap under the cabinet.

Toe kick dimensions table

Dimension	Common planning range	What to check
Toe kick height	About 100 to 165 mm	Many UK systems use adjustable legs and matching plinths. Howdens lists 165 mm plinth options.
Toe kick recess depth	About 50 to 75 mm	Enough room for toes without pushing the cabinet face too far back.
Finished worktop height	Often near 900 mm overall	Depends on base carcass, legs, worktop thickness and user comfort.
Plinth cut allowance	Site measured	Old floors can slope. Scribe and trim after the cabinets are fixed and level.

Toe kick dimension checker

Use this before ordering plinths or cutting the final kickboard.

Toe kick height in mm
Toe recess depth in mm
Floor condition

Enter the height and recess to check the planning band.

Why the toe kick matters

Standing comfort

The recess lets your feet tuck under the cabinet so you can stand closer to the worktop.

Clean line

A straight plinth hides adjustable legs and gives the kitchen a finished base line.

Appliance fit

Dishwashers, integrated appliances and ventilation grilles can change the plinth detail.

Uneven floors

The plinth often needs scribing. Cut it after the cabinets are level, not before.

Fitting sequence

Set the base units to the planned finished worktop height.
Level cabinets across the run before judging plinth height.
Check appliance doors, dishwasher clearance and ventilation needs.
Mark the plinth to the real floor, especially in older properties.
Clip or fix the plinth so it can still be removed for service access where needed.

Practical note: a 165 mm plinth product does not mean every kitchen will show exactly 165 mm at every point. Leg adjustment, floor finish and scribing can change the visible height.

For a kitchen where cabinet height, appliance clearance and plinth lines all need to land cleanly, see ABC Home’s kitchen fitting service in Aberdeen.

Sources and checks used

Howdens 165 mm plinths: useful reference for common UK plinth product height.
Wren Kitchens installation guides: installation sequencing and base cabinet setting context.

FAQ

What is the standard toe kick height?

A common planning range is about 100 to 165 mm, depending on the cabinet system and leg adjustment. Many UK plinth products are around 150 or 165 mm.

How deep should a kitchen toe kick be?

A recess around 50 to 75 mm is a practical starting point. It gives foot space without weakening the visual line of the base cabinets.

Is the toe kick the same as the plinth?

People often use the terms together. The toe kick is the recessed space; the plinth or kickboard is the panel that finishes the front.

Should flooring go under the plinth?

Often the finished flooring runs under or up to the plinth line depending on the floor type and installation plan. Decide this before final plinth cuts.
